A drill bit is a device attached to the end of the drill string that breaks apart, cuts or crushes the rock formations when drilling a wellbore, such as those drilled to extract water, gas, or oil.
The drill bit is hollow and has jets to allow for the expulsion of the drilling fluid, or mud, at high velocity and high pressure to help clean the bit and, for softer formations, help to break apart the rock.
A PDC bit has no moving parts and works by scraping the rock surface with disk-shaped teeth made of a slug of synthetic diamond attached to a tungsten carbide cylinder
Technical Specification
Model | PDC Bit, PDC Drag Bit |
Bit Size: | 4-1/2″ ~ 17-1/2” (114mm ~ 444.5mm) |
Blades: | 3 ~ 9 blades |
Nozzles: | according to customers’ requirement |
Cutters Size: | 1313, 1613, 1616, 1913, 1916, 1919 |
Material: | Carbide |
WOB (KN/mm): | 0.35 ~ 0.90 |
Rotary Speed (rpm): | 300 ~ 800 |
Customized: | Please provide bit size, IADC code, blade QTY., cutter type etc. |
