Model | YG60 | YG70 | YG80 | YG90 | YG110 | YG135 | YG160 | YG180 | YG225 |
Max load (kN) | 585 | 675 | 800 | 900 | 1125 | 1350 | 1580 | 1800 | 2250 |
Pulley OD (mm) | 610 | 610 | 610 | 760 | 760 | 760 | 760, 915 | 915 | 915 |
Pulley Qty | 4 | 3 | 3 | 3 | 4 | 4 | 4, 5 | 4 | 5, 6 |
Wireline dia. (mm) | 22 | 22 | 26 | 26 | 26 | 26 | 26, 29 | 32 | 29, 32 |
Hook type | Three | ||||||||
Hook open hole size (mm) | 110 | 110 | 110 | 110 | 150 | 152 | 180 | 190 | 190 |
Model | YG170 | YG315 | YG450 |
Max. hook load kN | 1700 | 3150 | 4500 |
O.D.of sheaves mm (in) | 915 (36) | 1270 (50) | 1524 (60) |
Number of sheaves | 5 | 6 | 6 |
Dia. of wire line mm (in) | 29 (11/8) / 32 (11/4) | 32 (13/8) / 35 (13/8) | 35 (13/8) / 38 (11/2) |
Major-hook opening mm (in) | 180 (7) | 220 (85/8) | 220 (85/8) |
Major-hook dia mm (in) | 150 (6) | 180 (7) | 180 (7) |
Minor-hook dia mm (in) | 90 (31/2) | 120 (43/4) | 120 (43/4) |
Overall dimension (LxWxH) mm | 3294x960x630 | 4322x1350x784 | 4887x1600x880 |
Our company is committed to study the unconventional oil and gas equipment, and oil and gas exploration equipment under special environment such as offshore, desert, shallow, rainforest and cold weather (polar region). At the same time, mechanization and intellectualization of equipment are improved and developed continuously. We developed the cold weather drilling rigs that can adapts to the 45℃ to -60℃ temperature, the series of drilling rig are exported to high-end market such as Russia and Canada. The truck-modular rigs and free-standing drilling rigs can meet the different requirements from the customer.
