Skid mounted drill machine is suitable for various oil, gas well drilling and exploration under 4000m at home and abroad. Equipped with optional digital controlled auto-driller system and driven by AC VF motors, driller can optimize the drilling parameters to conduct operation through touch-screen. In this way, the quality of well holes will be improved and the working strength of driller will be reduced as the working efficiency increases.
Structure Principles and Features
S/N | Description | Parameters |
1 | Nominal drilling depth | 2500 to 4000m (114mm DP) 2000 to 3200m (127mm DP) |
2 | Max. hook load | 2250kN |
3 | Drawworks rated power | 735kW(1000HP) |
4 | Drawworks gears | 4 gears |
5 | Max. wireline number of Traveling system | 10 |
6 | Drilling wireline dia. | φ32mm |
7 | Rotary table opening dia. | 698.5mm (27 1/2) |
8 | Rotary table gears of oil and gas drill rig | Gear step-less speed regulating |
9 | Mud pump type & number | F-1300 mud pumps 2 sets |
10 | Mast type and effective | Front opening type 43m |
11 | Substructure type & | Box block type 7.5m |
12 | Clearance | 6.3m |
13 | Rotary table electric transmission type | AC-SCR-DC |
14 | Control mode | 1 to control 2 |
Company Introduction
Our company is committed to study the unconventional oil and gas equipment, and oil and gas exploration equipment under special environment such as offshore, desert, shallow, rainforest and cold weather (polar region). At the same time, mechanization and intellectualization of equipment are improved and developed continuously. We developed the cold weather drilling rigs that can adapts to the 45℃ to -60℃ temperature, the series of drilling rig are exported to high-end market such as Russia and Canada. The truck-modular rigs and free-standing drilling rigs can meet the different requirements from the customer.
FRT regards continuous learning ability as one of the company’s core competitiveness and provides regular training to employees to enhance their comprehensive abilities and skills.
