The design of main parts is in compliance with related API provisions.
Model | ZJ40/2250D | ZJ50/3150D | ZJ70/4500D | ZJ80/5850D | ZJ90/6750D | ||||
Nominal depth range (114mm DP) m | 2500-4000 | 3500-5000 | 4500-7000 | 5000-8000 | 6000-9000 | ||||
Max hook load rating kN | 2250 | 3150 | 4500 | 5850 | 6750 | ||||
Max number of lines for traveling block | 10 | 12 | 12 | 14 | 14 | ||||
Dia.of wireline mm (in) | 32 (11/4) | 35 (13/8) | 38(11/2) | 42(15/8) | 45(13/4) | ||||
SheaveO.D.oftravelingblock mm (in) | 1120 (44) | 1270 (50) | 1524 (60) | 1524 (60) | 1524 (60) | ||||
I.D. of swivel stem mm (in) | 75 (3) | 75 (3) | 75 (3) | 101.6 (4) | 101.6 (4) | ||||
Rated power of drawworks kW (hp) | 735 (1000) | 1100 (1500) | 1470 (2000) | 2210 (3000) | 2210 (3000) | ||||
Transmission of drawworks | Stepless speed regulation | Stepless speed regulation | Stepless speed regulation | Stepless speed regulation | Stepless speed regulation | ||||
Dia. of rotary table opening mm (in) | 520.7 (201/2) | 698.5 (271/2) | 698.5 (271/2) | 952.5 (371/2) | 952.5 ( 371/2) | 952.5 ( 371/2) | 952.5  ( 371/2) | 1257.3 (491/2) | |
Rotary speeds | Stepless speed regulation | Stepless speed regulation | Stepless speed regulation | Stepless speed regulation | Stepless speed regulation | ||||
Power of a mud pump kW (hp) | 956 (1300) | 956 (1300) | 1176 (1600) | 1176 (1600) | 1176 (1600) | 1176 (1600) | 1620 (2200) | ||
Working height of mast m (ft) | 43 (142) | 45 (147) | 45 (147) | 48 (157) | 46 (151) | 48 (157) | |||
Height of drillfloor m (ft) | 7.5 (25) | 7.5 (25) | 9 (30) | 10.5 (35) | 10.5 (35) | 10.5 (35) | 12 (40) | ||
Clearheightunder rotary table beam m (ft) | 6.26(20.5) | 6.26 (20.5) | 7.6 (25) | 9 (30) | 8.92 (29.2) | 9 (29.5) | 10 (33) | ||
Notes | DB-Driven with A.C. motor with frequency converter | ||||||||
Our company is committed to study the unconventional oil and gas equipment, and oil and gas exploration equipment under special environment such as offshore, desert, shallow, rainforest and cold weather (polar region). At the same time, mechanization and intellectualization of equipment are improved and developed continuously. We developed the cold weather drilling rigs that can adapts to the 45℃ to -60℃ temperature, the series of drilling rig are exported to high-end market such as Russia and Canada. The truck-modular rigs and free-standing drilling rigs can meet the different requirements from the customer.
