SB 8x6 centrifugal sand suction pump

Description

SB Series Centrifugal pump is used for transferring slurry or mud or water. It can be used as feeding pump for desander, desilter, or used as mixing pump for Jet mud mixer. Also it can be used as trip pump, and supercharging pump for rig mud pump. All models centrifugal pumps use tungsten carbide mechanical seal, with famous brand Bearing. And spare parts interchangeable with most of the international Brand pump which helps customer to source spare parts easily. Open impeller design that lowers axial thrust loads, and make it easier for installation, repair and maintenance.

Centrifugal Sand Pump Specifications

Model	Flow (m3/h)	Lift (m)	Power (Kw)	Motor Speed(RPM)	Impeller (Inch)
SB8x6-14J	320m3/h	35m	75kW	1450RPM (50Hz)	14in
SB8x6-12J	320m3/h	35m	75kW	1750RPM (60Hz)	12in
SB8x6-13J	272m3/h	35m	55kW	1450RPM (50Hz)	13in
SB8x6-11J	272m3/h	35m	55kW	1750RPM (60Hz)	11in

Centrifugal Sand Pump Features and Benefits

1. All spare parts interchangeable with most of the international Brand pump which helps customer to source spare parts easily

2. Thick, Strong Concentric casing provides extended life over conventional volute designs. The Concentric design minimizes turbulence and abrasive wear.

3. Pump casing made from hard ductile iron alloy, increased abrasion resistant capability compared to competitors pump.

4. Wide open-vane impeller creates lower axial thrust for improved bearing life.

5. Pump impeller made from hard ductile iron alloy, extended life over competitors design.

6. Anti-loosening impeller lock bolt to eliminate pump damage in case of improper motor hook-up.

7. High quality no-adjustment mechanical seal to provide zero leakage and longer operation life.

8. Replaceable shaft sleeve prevents shaft wear.

9. All bearings from top brand for reliable operation.

10. The skid for supporting pump and motor is made from casting instead of welding to provide reliable operation and less vibration in a result to extend the pump and motor life.

Company Introduction

Our scope of business covers solid-liquid separation industries, such as petroleum drilling solid control system, trenchless mud purification system, gas coal seam exploration mud purification system, shield mud purification system, desilting purification system, pilework solid-liquid separation, environmental protection industry, etc. Company produces and deals in mud purification system, drilling fluid vibrating screen, mud cleaner, desander, desilter, vacuum degasser, centrifuge, shear pump, sand pump, gas-liquid separator, electronic ignition device, mud mixer, jet mud mixer, mud gun, mud tank, submerged slurry pump, solid control equipment accessories, etc.

Our production management strictly complies with the quality requirements of ISO9001 to provide reliable quality assurance from in-factory of raw material to ex-factory of finished products, which guarantee to provide customer-satisfied products.

We are committed to focusing on the challenges and pressures of customers' attention, providing competitive solutions and continuously creating the maximum value for customers. Safety and environmental and social responsibility are at the core of all our business activities.
